Arch Linux Remote Desktop via WSL2

Overview

This project is a complete guide and automation script set for running a full Arch Linux with XFCE4 graphical desktop inside WSL2 on Windows 11, accessible remotely via RDP from any device, without modifying router settings or opening any firewall ports. This is the key differentiator: instead of port-forwarding RDP (port 3389) through the router (which is often impossible on restricted networks, dorms, or corporate environments), the RDP traffic is tunneled outward through Cloudflare Tunnel.

The architecture works by running xrdp inside the WSL2 Arch Linux environment on the standard RDP port, then running a cloudflared tunnel daemon that creates an encrypted outbound connection to Cloudflare's edge network. On the client side, cloudflared access rdp authenticates through Cloudflare Access and opens a local listener; any standard RDP client then connects to localhost:3389, and the traffic is routed through the tunnel to xrdp. No inbound ports, no static IP required, no router access needed.

Architecture

Tech Stack

• Arch Linux, rolling-release Linux distribution running inside WSL2
• WSL2, Windows Subsystem for Linux 2, Hyper-V-based VM layer in Windows 11
• XFCE4, lightweight GTK desktop environment for the graphical session
• xrdp + xorgxrdp, open-source RDP server for Linux, compiled from AUR
• Cloudflare Tunnel (cloudflared), outbound tunnel daemon, eliminates need for port forwarding
• Windows 11, host OS with WSL2 and Hyper-V enabled
• pacman / yay, Arch package manager and AUR helper

Build Process

# In PowerShell (as Administrator):
# Update WSL, then install Arch from the official feed
wsl --update
wsl --install archlinux

# Launch Arch
wsl -d archlinux

# Inside Arch:
pacman-key --init
pacman-key --populate archlinux
pacman -Syu --noconfirm

# Create user with a validated sudoers drop-in
useradd -m -G wheel -s /bin/bash yourusername
passwd yourusername
echo "%wheel ALL=(ALL:ALL) ALL" | sudo tee /etc/sudoers.d/wheel
sudo chmod 440 /etc/sudoers.d/wheel
sudo visudo -c

pacman -S xfce4 xfce4-goodies \
    xorg-server xorg-xinit \
    ttf-dejavu ttf-liberation \
    gtk3 adwaita-icon-theme \
    dbus --noconfirm

# Verify XFCE components are installed
pacman -Qs xfce4 | grep "local/"

# Install yay AUR helper (run as non-root user)
pacman -S git base-devel --noconfirm
git clone https://aur.archlinux.org/yay.git /tmp/yay
cd /tmp/yay && makepkg -si --noconfirm

# Install xrdp and xorgxrdp from AUR
yay -S xrdp xorgxrdp --noconfirm

# These packages compile from source - takes a few minutes on a modern CPU
# Verify installation
xrdp --version

# Create the .xsession file for your user
echo "startxfce4" > ~/.xsession
chmod +x ~/.xsession

# Also create a system-wide fallback
sudo bash -c 'echo "startxfce4" > /etc/xrdp/startwm.sh'
sudo chmod +x /etc/xrdp/startwm.sh

# Verify the file content and permissions
cat ~/.xsession
ls -la ~/.xsession

# /etc/wsl.conf
[boot]
systemd=true

# Save the file, then restart WSL2 from PowerShell:
# wsl -shutdown
# wsl -d Arch

# Back inside Arch, start xrdp
sudo systemctl enable xrdp xrdp-sesman
sudo systemctl start xrdp xrdp-sesman
sudo systemctl status xrdp

# Confirm xrdp is listening on port 3389
ss -tlnp | grep 3389

# Install cloudflared (AUR)
yay -S cloudflared --noconfirm

# Authenticate with Cloudflare (opens browser)
cloudflared tunnel login

# Create a named tunnel
cloudflared tunnel create rdp-tunnel

# Route a DNS hostname to the tunnel (use your own domain)
cloudflared tunnel route dns rdp-tunnel rdp.example.com

# Create tunnel config (the final rule is a mandatory catchall)
mkdir -p ~/.cloudflared
cat > ~/.cloudflared/config.yml << 'EOF'
tunnel: rdp-tunnel
credentials-file: /home/yourusername/.cloudflared/<TUNNEL-ID>.json

ingress:
  - hostname: rdp.example.com
    service: rdp://localhost:3389
  - service: http_status:404
EOF

# Start the tunnel
cloudflared tunnel --config ~/.cloudflared/config.yml run rdp-tunnel

# Or run as systemd service
cloudflared service install
systemctl enable cloudflared
systemctl start cloudflared

# In the Cloudflare Zero Trust dashboard, create an Access application for
# rdp.example.com with a policy allowing your identity.

# On the client machine (cloudflared installed):
cloudflared access rdp --hostname rdp.example.com --url rdp://localhost:3389

# Then connect your ordinary RDP client to localhost:3389:
# Windows: mstsc -> Computer: localhost:3389, Username: yourusername
# macOS: Microsoft Remote Desktop -> Add PC -> PC name: localhost:3389
# Linux: xfreerdp /v:localhost:3389 /u:yourusername /dynamic-resolution

Request Flow

Challenges & Solutions

• xrdp black screen on connect: The most common issue with xrdp on Linux is connecting successfully but seeing only a black screen. This is caused by the ~/.xsession file being absent, empty, or not executable. Resolved by creating the file with echo "startxfce4" > ~/.xsession && chmod +x ~/.xsession and ensuring the file belongs to the correct user account.
• systemd not available in WSL2 by default: Before enabling systemd, systemctl commands returned errors and xrdp could not be managed as a service. Resolved by adding [boot] systemd=true to /etc/wsl.conf and running wsl -shutdown from PowerShell to restart the WSL2 instance with systemd as PID 1.
• xorgxrdp AUR compilation failures: Building xorgxrdp from the AUR required specific Xorg development headers that were not pulled in automatically. Resolved by installing xorg-server-devel and xorgproto before running the AUR build, and ensuring base-devel was fully installed.
• Cloudflare Tunnel not reconnecting after WSL2 restart: The cloudflared process terminated when WSL2 was shut down and did not restart automatically. Resolved by running cloudflared service install to register it as a systemd service, which then starts automatically when WSL2 boots with systemd enabled.

What I Learned

• WSL2 internals: Hyper-V-based VM, network bridge, and the role of wsl.conf
• xrdp session lifecycle: xsession file, display allocation, and xorgxrdp module loading
• Cloudflare Tunnel architecture: outbound-only tunnels, credential files, and ingress routing
• AUR package compilation: makepkg, PKGBUILD review, and dependency resolution
• systemd in WSL2: enabling it, service unit management, and boot sequence changes
• Remote desktop protocol fundamentals: session negotiation, display encoding, and input forwarding

How I built it

The build started from a simple constraint: I wanted a full Linux desktop I could reach from anywhere, even from networks where port forwarding is impossible. That ruled out exposing RDP directly and pushed the design toward an outbound tunnel.

1. Phase 1, install Arch inside WSL2: Installed Arch with wsl --install archlinux from the official WSL feed, initialized the pacman keyring, ran a full system upgrade, and created a non-root user with a validated sudoers drop-in.
2. Phase 2, install the XFCE4 desktop: Installed XFCE4 as the desktop environment for its low memory footprint, which matters inside a virtualized WSL2 guest.
3. Phase 3, compile the RDP server from AUR: Installed xrdp and xorgxrdp with the yay AUR helper, then configured the session startup so RDP logins launch the XFCE session.
4. Phase 4, tunnel RDP through Cloudflare: Ran cloudflared so the RDP traffic flows out through a Cloudflare Tunnel. No router changes and no open firewall ports are needed, which is what makes this work on dorm, corporate, and restricted networks.
5. Phase 5, automate everything: Packaged the whole sequence into scripts so the setup is repeatable: one import, one desktop install, one RDP compile, one tunnel command.

What you need

Challenges and lessons learned

• Compiling xrdp from source: the AUR build pulls in Xorg development headers, so a minimal Arch install needs the base-devel group first. Lesson: script the dependency install before the AUR step, or the build fails halfway.
• Session startup wiring: getting xrdp to hand off to XFCE instead of a bare X session took several tries editing the session scripts. Lesson: test the RDP login after every config change rather than batching edits.
• Tunnel versus direct RDP: tunneling adds a small latency hop, but the tradeoff is worth it when port forwarding is not an option. Lesson: pick the architecture that fits the network you actually have, not the ideal one.

What is next

• Add an optional GPU-accelerated path using xorgxrdp-glamor for smoother rendering on capable hosts.
• Package the scripts into a single one-command installer with sanity checks for each stage.
• Evaluate Tailscale as an alternative transport for networks where Cloudflare Tunnel is blocked.
• Document a Wayland-based variant as Wayland session support in RDP servers matures.
