Self-Hosted DNS

Overview

This project replaces the default ISP DNS resolver with a fully self-hosted, two-layer DNS stack. Pi-hole acts as the network's primary DNS server, intercepting every DNS query from every device on the LAN. When a domain appears on any of the configured blocklists (ad networks, trackers, malware domains), Pi-hole returns a blocked response immediately (0.0.0.0 for A queries and :: for AAAA queries, Pi-hole's default NULL blocking mode). Allowed queries are forwarded to Unbound, a validating recursive resolver that walks the DNS tree from the root nameservers rather than trusting a third-party upstream like Google (8.8.8.8) or Cloudflare (1.1.1.1).

The stack runs in Docker containers on a Proxmox LXC container using a macvlan network so Pi-hole gets its own IP on the LAN, allowing the router's DHCP to advertise it as the DNS server for all connected devices. Blocklists from Steven Black and OISD block well over one hundred thousand ad, tracker, and malware domains (the exact count changes with every list update). DNSSEC validation is enabled in Unbound for additional query integrity, with Pi-hole-side validation left off to avoid validating twice.

Architecture

Tech Stack

• Pi-hole, DNS sinkhole with web dashboard and blocklist management
• Unbound, validating, recursive, caching DNS resolver with DNSSEC
• Docker & Docker Compose, container runtime for both services
• pihole-FTL, Pi-hole's integrated DNS/DHCP engine (dnsmasq-derived, embedded in v6)
• macvlan, Docker network driver giving Pi-hole its own LAN IP
• Linux (Debian), host OS inside Proxmox LXC container

Build Process

# Create the macvlan Docker network
docker network create \
  -d macvlan \
  -subnet=192.168.1.0/24 \
  -gateway=192.168.1.1 \
  -o parent=eth0 \
  macvlan_net

# docker-compose.yml for Pi-hole + Unbound
# Both containers share an internal network so Pi-hole can reach Unbound
# as unbound#5335; Pi-hole also sits on macvlan for its own LAN IP.
services:
  pihole:
    image: pihole/pihole:latest
    container_name: pihole
    hostname: pihole
    networks:
      macvlan_net:
        ipv4_address: 192.168.1.53
      dns_internal:
    environment:
      TZ: "America/Toronto"
      # Pi-hole v6 variable names (v5 names like WEBPASSWORD no longer work)
      FTLCONF_webserver_api_password: ${PIHOLE_PASSWORD:?set a password in .env}
      FTLCONF_dns_upstreams: "unbound#5335"
      # Leave Pi-hole-side DNSSEC off: Unbound already validates (see Step 2)
      FTLCONF_dns_dnssec: "false"
    volumes:
      - ./pihole/etc-pihole:/etc/pihole
      - ./pihole/etc-dnsmasq.d:/etc/dnsmasq.d
    restart: unless-stopped

  unbound:
    image: mvance/unbound:latest
    container_name: unbound
    hostname: unbound
    networks:
      dns_internal:
    ports:
      - "127.0.0.1:5335:5335/udp"
      - "127.0.0.1:5335:5335/tcp"
    volumes:
      # Mount the whole config directory: unbound.conf, root.hints, and the
      # writable root.key trust anchor all live here inside the container
      - ./unbound:/opt/unbound/etc/unbound
    restart: unless-stopped

networks:
  macvlan_net:
    external: true
  dns_internal:

# ./unbound/unbound.conf (mounted into the unbound container)
server:
    verbosity: 0
    interface: 0.0.0.0
    port: 5335
    do-ip4: yes
    do-udp: yes
    do-tcp: yes
    do-ip6: no

    # Only answer the internal Docker network
    access-control: 127.0.0.1 allow
    access-control: 172.16.0.0/12 allow

    # Root hints
    root-hints: "/opt/unbound/etc/unbound/root.hints"

    # DNSSEC
    auto-trust-anchor-file: "/opt/unbound/etc/unbound/root.key"

    # Security
    hide-identity: yes
    hide-version: yes
    harden-glue: yes
    harden-dnssec-stripped: yes
    use-caps-for-id: yes

    # Performance
    cache-min-ttl: 3600
    num-threads: 2

# Download root hints next to the config before first start
wget -O unbound/root.hints \
  https://www.internic.net/domain/named.cache

docker compose up -d unbound
docker compose logs unbound

# Set via environment variable in docker-compose.yml:
FTLCONF_dns_upstreams: "unbound#5335"

# Verify Pi-hole forwards to Unbound
docker exec pihole pihole -d | grep "DNS"

# Test full resolution chain from the host
dig @192.168.1.53 github.com

# On OpenWrt, advertise Pi-hole via DHCP option 6
# (Network > Interfaces > LAN > DHCP Server > Advanced > DHCP-Options):
# 6,192.168.1.53
# Note: this is different from "DNS forwardings", which controls where the
# router itself forwards queries, not what it tells DHCP clients to use.

# For dnsmasq-based routers (/etc/dnsmasq.conf):
dhcp-option=6,192.168.1.53

# Verify a client received the correct DNS server
# On any LAN device:
nslookup - 192.168.1.53
> google.com

# Check Pi-hole dashboard for new queries appearing
# http://192.168.1.53/admin

# Blocklist URLs to add in Pi-hole dashboard:
# Steven Black unified hosts:
https://raw.githubusercontent.com/StevenBlack/hosts/master/hosts

# OISD full list:
https://big.oisd.nl/domainswild

# After adding lists, update gravity:
docker exec pihole pihole -g

# Check gravity count
docker exec pihole pihole -q example-ad-domain.com
docker exec pihole sqlite3 /etc/pihole/gravity.db \
  "SELECT COUNT(*) FROM gravity;"

# Test that a known ad domain is blocked
dig @192.168.1.53 doubleclick.net
# Expected: 0.0.0.0 (Pi-hole's default blocking mode)

# Test that a regular domain resolves
dig @192.168.1.53 github.com
# Expected: valid A record

# Check recursive resolution via Unbound directly
dig @127.0.0.1 -p 5335 github.com

# Confirm DNSSEC validation is working
dig @127.0.0.1 -p 5335 sigfail.verteiltesysteme.net
# Expected: SERVFAIL (DNSSEC failure detected correctly)

Request Flow

Challenges & Solutions

• Docker macvlan container cannot reach the host: By default, a container on a macvlan network cannot communicate with the host machine running Docker, because macvlan bypasses the host network stack. This would have prevented Pi-hole from talking to Unbound on the host loopback. Resolved by running Unbound in a second container attached to a shared internal Docker network; Pi-hole reaches it as unbound#5335, sidestepping macvlan's host isolation entirely.
• DNS loop between Pi-hole and Unbound: When both resolvers listen on port 53, Pi-hole can forward queries to Unbound, which in some configurations forwards back to Pi-hole. Resolved by running Unbound strictly on port 5335 and pointing Pi-hole upstream explicitly to unbound#5335, ensuring a one-way forwarding chain.
• Gravity update failing inside container: The pihole -g command failed because the container initially had no working outbound route to download blocklists. Fixed by correcting the macvlan gateway and default route so the container can reach the internet during gravity updates.
• Some legitimate domains blocked: OISD's full list occasionally blocks CDN subdomains used by legitimate services. Whitelisting is managed via the Pi-hole dashboard under Whitelist, and the OISD basic list is used instead of the full list for stricter environments.

What I Learned

• DNS resolution hierarchy: root nameservers, TLD delegation, and authoritative records
• DNSSEC validation chain and how SERVFAIL signals a tampered record
• Docker macvlan networking and its limitations with host communication
• Pi-hole gravity database structure and SQLite query patterns
• The performance impact of recursive vs forwarding DNS (latency vs privacy)
• Router DHCP option 6 for network-wide DNS distribution without per-device config

How I built it

ISPs log DNS, and third-party resolvers see every domain your household looks up. This stack keeps resolution in-house: Pi-hole filters the junk, Unbound walks the DNS tree itself, and nothing is forwarded to Google or Cloudflare.

1. Phase 1, deploy Pi-hole with its own IP: Created a Docker macvlan network so Pi-hole gets a dedicated address on the LAN, letting the router advertise it as the DNS server via DHCP with zero per-device configuration.
2. Phase 2, add the recursive resolver: Deployed Unbound as the upstream: a validating recursive resolver that walks from the root nameservers instead of trusting a third party, with DNSSEC validation enabled.
3. Phase 3, load the blocklists: Subscribed to the Steven Black and OISD lists, blocking well over one hundred thousand ad, tracker, and malware domains at the DNS layer (counts change with every update).
4. Phase 4, cut over the network: Pointed the router's DHCP DNS advertisement at Pi-hole so every device on the LAN picks it up automatically.
5. Phase 5, containerize on Proxmox: Runs the whole stack in Docker inside a Proxmox LXC container for easy snapshots and migration.

What you need

Challenges and lessons learned

• macvlan host isolation: with macvlan, the Docker host itself cannot reach the Pi-hole container IP. Lesson: manage it from another LAN device or add a macvlan shim interface on the host.
• False positives: aggressive lists occasionally break legitimate sites or apps. Lesson: keep the Pi-hole audit log handy and whitelist deliberately; the dashboard makes the offending domain obvious.
• DNSSEC validation failures: misconfigured domains fail validation and look like outages. Lesson: learn to read Unbound logs so a broken remote domain is not mistaken for a local problem.

What is next

• Deploy a secondary resolver so DNS survives maintenance on the primary.
• Offer DNS-over-HTTPS as an optional upstream for specific clients.
• Use Pi-hole client groups for per-device policies, such as stricter filtering for IoT.
• Build query-log analytics to spot new trackers and compromised devices.
